MPPT 60A 12V 24V 36V 48V Auto LCD Display Solar Charger Controller Solar Panel Batteries Charge Regulator EU RU US Warehouse
4.9 (7 votes) | 28 orders
Price:
US $314.43 - 399.65
/ piece
Discount Price:
US $
178.17 -
221.24
/ piece
-43%
- Ships From
MPPT 60A 12V 24V 36V 48V Auto LCD Display Solar Charger Controller Solar Panel Batteries Charge Regulator EU RU US Warehouse
This is 100% PowMr MPPT Solar Charger Controller ,12V 24V 36V 48V Auto work , it is used for Lead acid ,gel , lithium battery . we have 30A 40A 50A 60A.
100% MPPT controller
Intelligent Maximum Power Point Tracking technology
Built-in DSP controller with high performance
Automatic battery voltage detection 12V/24V/36V/48V
Three-stage charging optimizes battery performance
Multi-function LCD displays
Reverse polarity protection of solar panel
Overcharge protection
Can be mounted easily
Suitable for battery types of sealed lead acid, vented Gel, and Lithium battery
Notes: The output terminal is for lamp only ( 12V system less 60W, 24V/36V/48V system less 100W ),and it will be burnt if connecting to other loads. The output for battery is no polarity reverse protection.
Package Include
1 PCS MPPT Solar Controller
1 PCS English User Manual
Model No. | MPPT-60A |
Charging mode | MPPT Maximum power point tracking automatically |
Charging | 3-stage:constant current(MPPT), constant voltage(Absorption Voltage), floating charge |
System type | DC12V/24V/36V/48V Recognition automatically |
System voltage automatic recognition | 12V system (DC9V-DC15V) |
24V system (DC18V-DC29V) | |
36V system (DC30V-DC39V) | |
48V system (DC40V~DC60V) | |
Soft start time | ≤1S |
Dynamic response and recovery time | 100us |
Max efficiency | ≥98.1% (Voc is 1.5 or 2 times than battery, then it’s best efficiency) |
PV utilization | ≥99% |
Input specification | |
Voc from PV ( Make sure the Voc of PVmeeting the requirement as right. Voc is 1.5 or 2 times than battery, then it’s best efficiency. ) | 12V system (DC20V~DC80V) |
24V system (DC37V~DC105V) | |
36V system (DC50V~DC160V) | |
48V system (DC72V~DC160V) | |
The maximum PV input voltage (Voc) | DC190V(The controller can’t work at this voltage of long duration that will break controller. Please refer to Input voltage from PV.) |
The maximum PV input power (The total power rated of PV can’t be over this watt that will break the controller.) | 12V system (720W) |
24V system (1440W) | |
36V system (2100W) | |
48V system (2800W) | |
Output specification | |
Selectable battery type(default is Sealed) | Vented/ Sealed / Gel / NiCd / Lithium battery(defined voltage for other battery by user) |
Absorption Charging Voltage | Refer to Batteries charging reference |
Floating Charging Voltage | |
Overcharging protection voltage | 12V system (15V) |
24V system (30V) | |
36V system (45V) | |
48V system (60V) | |
Rated output current | 60A |
Temperature Coefficient | ±0.02%/ centi-degree |
utomatic temperature compensation | 14.2V-(Max temperature-25 centi-degree)*0.3 |
Output voltage ripple-peak | 100mV |
Output voltage accurac | ≤±1% |
Input Anti-intrusion protection | yes |
Temperature Protection | 75°C |
Temperature increased protection | Output power will reduce when it’s more 70 °C Output power will be normal when it’s less 55 °C |
Fan-on temperature | >40 °C |
Fan-off temperature | <35 °C |
Acoustic noise | ≤40dB |
Cooling way | Forced air cooling. |
Components | Imported materials, Accord to EU standards, Industrial grade range. |
Environmental requirements | Meet 2002/95/EC; No cadmium, hydrides and fluorides |
Security Level | Accord to CE, PSE, FCC, EMC, EN60950 |
Electromagnetic Compatibility | Accord to EN61000, EN55022, EN55024 |
Enclosure | IP21 |
- is_customized: Yes
- Maximum Current: 60A
- Model Number: MPPT-60A Solar Controller
- Application: Solar System Controller,Voltage Controller,Lighting Controller,Thermal Controller
- Brand Name: PowMr
- Origin: Mainland China
- Certification: CE
- Charging mode: MPPT (Maximum power point tracking)
- Battery Voltage: 12V/24V/36V/48V Auto Recognition
- Battery type: Vented Sealed Gel NiCd LiFePO4 Lithium Battery
- Maximum Solar Panel input: 12V ( 80V) 24V (105V) 36V(160V) 48V(160V)
- Cooling way: Fan
- Case Material: Aluminum
- The maximum PV input voltage (Voc): DC190V
- Version: 2018 Newest
