1 Pcs 40A/60A/100A MPPT Solar Panel Regulator Charge Controller 12V/24V Auto Focus Tracking AU

0.0 (1 votes) | 6 orders
Price: US $1613.88 - 2217.30 / piece
Discount Price:
US $ 1295.42 - 1778.14 / piece
-20%
Current
Quantity

Our product is to track the current focus of the MPPT to adjust the

 internal charging mode to maximize the conversion of light energy

into electrical energy. It is not the voltage tracking, It not the low voltage

or the high voltage is converted to the specific value of the constant

voltage to track the MPPT, so as not to cause misunderstanding







SAFETY INSTRUCTIONS

1. Make sure your battery has enough voltage for the controller to recognize the battery type before first installation.

2. The battery cable should be as short as possible to minimize loss.

3. The regulator is only suitable for lead acid batteries:OPEN,AGM,GEL it is not suited for nickel metal hydride,lithium ions or other batteries.

4. The charge regulator is only suitable for regulating solar modules. Never connect another charging source to the charge regulator.



                                                                             Features:

1. Industrial-grade main control chip, 16-level AD sampling accuracy, accurate real-time display of temperature, charging current and discharge current, and the power generation is clear at a glance.
2, automatic focus MPP tracking charging, high charging efficiency, charging process does not pause detection, two-way focus tracking.
3, large-screen LCD display, adjustable charging and discharging parameters, ultra-wide charge and discharge adjustable, as long as you understand the battery characteristics set its corresponding charging parameters, you can charge any battery, the output can be adjusted when the power is off, more convenient ( There is no adjustment in the market).
4, complete 3-stage charge management, effectively protect the battery, the battery is more durable.
5, built-in overheating, overcurrent, short circuit, open circuit protection, reverse connection protection, when the fault is eliminated, the controller automatically responds without damaging the device.
6, two-way moss tube placed in the irrigation circuit, high-power charging mode, ultra-low heat.

51







                                                                   ARAMETER



MODEL

BL912A

BL912B

BL912C

BL912D

       BL912E

Batt voltage

12V/24V auto

Charge current

30A

40A

50A

     60A

100A

Discharge current

10A

        10A

        20A

       20A

30A

Max solar input

12V battery, the highest 23V; 24V battery when the highest 46V

Equalization

14.4V

Float charge

13.7V (defauhadjustable)

Discharge stop

10.7V defaul,adjustable*

Discharge reconnect

12.6 V(defaul,adjustable)

Charge reconnect

13V

Voltage of open light

Solar panel 8V(Light lights delay)

Voltage of close light

Solar panel 8V(Light off delay)

USB output

2 way USB output 5V/2.5A(MAX)

Self-consume

<10mA

Operating temperature

・35〜+60C

Size/Weight

170 *92* 45mm / 450g













  • is_customized: Yes
  • Maximum Current: 100
  • Model Number: 12V/24V
  • Application: Charger Controller
  • Brand Name: BLUSUNSOLAR
  • Certification: CE
  • Origin: Mainland China
