RD TC66/TC66C Type-C PD trigger USB-C Voltmeter ammeter voltage 2 way current meter multimeter PD charger battery USB Tester
4.9 (100 votes) | 405 orders
Price:
US $48.66 - 83.21
/ piece
Discount Price:
US $
39.41 -
67.41
/ piece
-19%
- Ships From
- Color
-
-
Model: TC66/TC66-C
Display screen：0.96Inch color IPS display
Voltage measurement range:0.0050-30.0000V
Voltage measurement resolution:0.0001V(0.1mV)
Current measurement range: 0-5.00000A
Current measurement resolution: 0.00001A(0.01mA)
Supply voltage:3.5-24V
Screen Resolution: 160*80
Capacity accumulation range: 0-99999mAh
Voltage measurement accuracy:±(0.05％+20digits at 23℃)
Energy accumulation range:0-99999mWh 999.99Wh
Current measurement accuracy: ±(0.1％+30 digits, at 23℃)
Load impedance range: 1Ω-9999.9Ω
Power measurement range:0-150W
Temperature measurement range:0℃~45℃/32℉~113℉
Refresh rate: 2Hz
Working temperature range: 0~45℃/32℉~113℉
Auto screen off time: 0-9mins
Dimensions：49mmx22mmx8mm
Product weight: about 8g (withpackage 22g)
Quickchargerecognition mode：QC2.0、QC3.0、Apple2.4A/2.1A/ 1A/0.5A、Android DCP、Samsung
1,Instruction: User manual, PC software installation instruction and PC software and Android APP download link: Main link:http://www.mediafire.com/folder/pqn0ybytqpy7n/TC66 backup link:https://drive.google.com/drive/folders/1JS4mnXdM_VRUYa0ueRQUDR69b1_Lt7iG?usp=sharing 2,APP Download: IOS APP:search "TC66C" in iPhone APP store Android APP: search "RuiDeng" in google play |

At present, the TC66C PC software is not compatible with Czech and Korean language windows systems. We are UPDATING it. If you mind, please do not buy. DO NOT install the PC software at DISK C, please install the software at other disks 2, Correct Operation TC66 uses the double-headed Typec line for the decoy triggering operation, only one side can be used. If the screen does not light, please flip the interface. 3, Video Operation and test video:https://youtu.be/SCVcSjDMx2g 4, Electronic USB Load For electronic USB load, we have HD series and LD series 25W 35W load, you can choose by yourself, HD series has trigger mode, LD series only normal mode  PRODUCT QUESTIONS： 1. Q:What is the differences between TC66 and TC66C? A: TC66 is no communication version, TC66C is conmmunication version by Bluetooth connection, both of them can connect to PC software by USB connection 2. Q:The firmware of the product I receive is not the latest? A: Because the firmware is updated when there is something changing, so you can use the PC software to update the firmware 3. What should I do with the PD switch? A:When using TC66 to detect the charger protocol, it is necessary to turn on the PD Switch. When using TC66 to detect the charging process of mobile phone, it is necessary to turn off the PD Switch.(No matter it is the hardware switch or the System Setting) 4.What should I do with the PWR switch? A:PWR switch means System power. When in use, set it to ON. If the voltage is less than 3.5v, use Micro to supply power independently and set the PWR switch to OFF. 5.I insert it to a PD charger but it does not light? A:under normal mode(turn off the trigger switch), when insert TC66(C) in to a charger, it will not light because according to the work principle of Type-C port, only when there is load connected, there will be current flow and TC66(C) will light. there are two ways:① you need to connect a load which supports PD protocol too,so that the display will work, ② you can choose to use trigger mode, so that the display will light without connecting a load
6.Does the software has virus, it has warning by the defender? A:when you download the file and install the PC software, some windowns virus system will warning and take it as virus, please allow this function or closed the virus system, becuase our file and sofware did not have virus, it was design by our company, some virus system don't know this, it will take all unknown things as system, but we can make sure 100% that there is not virus, if you are care , please stop buying our products.....when you download the file and install the PC software, some windowns virus system will warning and take it as virus, please allow this function or closed the virus system, becuase our file and sofware did not have virus, it was design by our company, some virus system don't know this, it will take all unknown things as system, but we can make sure 100% that there is not virus, if you are care , please stop buying our products..... SOFTWARE QUESTIONS: 1. Q: what is the software crash problem? ①There may be incompatibilities problems of the PC software with some Windows systems, if you really need it, please install and test the software before buying the product. ②There are many types of mobile phones and operation systems, so there may be incompatibilities, if you need APP, please install and test the APP before buying the product. ③If you don't test the PC software and APP function before buying and find that the products works fine except the PC software or APP, we refuse to refund. ④Please do install and test the APP if you use Samsung mobile phone.
| ||||||||||||||||||||||||||||||||||||||||||||||
- Power Supply: DC
- Model Number: TC66/TC66C
- Dimensions: 49mmx22mmx8mm
- Operating Temperature: no
- Accuracy Class: no
- Display Type: Digital Only
- DIY Supplies: ELECTRICAL
- Brand Name: RD
- Origin: Mainland China
- Certification: CE,FCC
- Voltage measurement range: 0.005V-30.0000V
- Current measurement range: 0-5.00000A
- Voltage measurement resolution: 0.0001V
- Current measurement resolution: 0.00001A
- Product weight: 7g
- Display screen: 0.96 Inch color IPS display
- Update rate: 2Hz
- Capacity accumulation: 0-99999mAh
- PD triger: yes
- USB Communication: for TC66/TC66C by PC software
- Bluetooth communication: only for TC66C by APP of android and IOS
- Current flow: 2 ways
- firmware update: yes by PC software
- independent power supply: yes
