CM-280S Lead-free Double digital Solder Pot Soldering Soldering Desoldering Bath 280*200*45mm 21.2KG 2000W

Customer from following coutry Need to pay extra EMS/DHL/UPS shipping cost,if you accept,please contact us for future information:

Brazil,Russia,Israel,Czech Republic,Poland,Hungary,Croatia,Ukraine,South Africa,Latvia,India,Argentina,Slovenia,Kazakhstan,Estonia,United Arab Emirates,Lithuania,Bulgaria,Romania,Belarus,Saudi Arabia,Colombia,Brunei,Cyprus,Maldives,Uruguay,Serbia and Montenegro,French Polynesia,Macedonia,Serbia,Kuwait,Bahrain,Botswana,Netherlands Antilles,Armenia

Free Shipping -- DHL,UPS,EMS

Description:

CM-280S Lead-free Double digital Solder Pot Soldering Soldering Desoldering Bath 280*200*45mm 21.2KG 2000W

Specifications:

Precautions

1. Melting furnace must be placed on a stable, heat-resistant work Taiwan work, to prevent heat tin from tin pan spill. The molten tin and tin furnace temperature is higher overall, be careful work to guard against burns.
2. Tin stove during the initial use, please do not cause air burning tin pot tin oxide quickly, please add small pieces of tin or part of the solution to ensure timely tin heat.
3. Must be placed separately and have solder furnace (including lead all items) to prevent lead contamination, so no change there Tin Tin, lead to product failure when lead-free melting furnace work. The company this serious statement, if such things happen, the company does not assume any responsibility.
4. Prohibit the use of melting furnace in the vicinity of flammable gases and flammable items.
5. When moving melting furnace must be cut off power supply when the furnace is cooled to room temperature and then proceeds.
6. This product is a high-temperature device, remember to turn off the power when not in use, to avoid accidents.
7. For tin stove safety and service life, do not exceed continuous furnace12H.
8. For personal safety and machine to work properly, remember not air burning, used to take the "ground" of power use, while paying attention to "ground" unacceptable "zero line".
9. The company melting furnace furnace imported from Japan TitaniumTAIMaterials from refined, high-temperature burning time after a tin pot pot surface become golden or blue, which is a normal phenomenon, but also the material properties of the metal.
10. The product quality assurance is that all parts are made under conditions of the branded original accessories, or quality is not guaranteed.
11. In the case of customer use, cook acids, bases, tin slag and other strong corrosive material, tin pot and the heating element will not warranty.
12. The furnace belong not waterproof, and pay attention to moisture in use.

One,Overview:

The company developed theCMTitanium metal-free solder furnace, has passed authoritySGSEnvironmental certification, is environmentally friendly lead-free, customers can be assured that the product of tin mining pan (preheat platform aluminum) pan using imported titanium material and the corresponding production technology; with microcomputer chipPIDIntelligent control, a safe, reliable, stable performance, high precision, is the ideal tool for the production of the field of electronic wire industry indispensable.

Features:

1,CmSeries of lead-free solder furnace configuration power heater, quickly dissolve without Tin, arrive from room450, only25Minutes (specific nuances will be based on the size of the furnace volume).

2,Microcomputer chip intelligent control, dual digital display, clear and intuitive, high thermal sensitivity, warmed rapidly, fast temperature compensation.

3,Free solder pot materials made of imported titanium, high temperature, corrosion resistance, abrasion resistance and durability.

4,The furnace is set directly input data using the touch buttons, simple and accurate.

5,Machine data set long-term preservation, is not shut down, outages.

Working environment:

1,Operating Voltage:AC22010V(Can be customized110V??

2,Operating temperature:0--55Degree

3,Working temperature: <90% RHNo condensation

Methods of operation and function setting:

1,Temperature setting:

(1)Open the furnace power switch, the operator panel displaysTemperature measurements3.0.0Temperature setpoint2.8.0.0.Direct useAdd+OrLess-Keys to adjust the temperature setting, pressAdd+OrLess-Key will increase or decrease a unit, pressAdd+OrLess-Key to a continuous rise or fall, the value of the set temperature is automatically set after long-term storage in seconds, not switch, power influence.

(2)Open the tin stove power operator panelDisplay temperature measurements3.0.0Temperature setpoint2.8.0.0.Use the shift key to type * to adjust the temperature setpoint, which figures behind the decimal point to stop in, you can use this numberAdd+OrLess-Keys to adjust. The set temperature is automatically set after long-term storage in seconds, not switch, power outages affected.

2, Microcomputer auto-tuning:

If the measured temperature and the temperature set point deviation is too high (3-5Degrees), or temperature measurements and the actual oven temperature deviation is too high (10-20Degrees). Perform the auto-tuning operation, press and hold the shift key * three seconds the thermostat will automatically enter the self-tuning state, the displayATAnd the set temperature, and two subtitle will not stop cross flashing, direct20Minute-40Minute self-tuning end, will normally display the temperature you set. Since when scaling is not the end, if you want to quit and then press the shift key * and hold until the flashing stops can be. The factory is to optimize the value of the parameter, generally do not auto-tuning.

3??Temperature difference compensation:

If the temperature measurements and the actual temperature of the furnace after the auto-tuning or error is too high, you can use the following method of correction.

(1)Press and holdCALFunction key for two seconds, the displayTemperature measurements5cTemperature setpoint0.0Proceed as+ -Key to compensate. Compensation is completed, pressCALFunction key twice to save and exit.

Example: the measured temperature is higher than the actual temperature furnace10When degrees, withLess-Keys to adjust to the temperature measurements5cTemperature setpoint-10, Then press the function keyCALSave and exit. In contrast, the measured temperature is lower than the actual temperature of the furnace10When degrees, withAdd+Keys to adjust toTemperature measurements5cTemperature setpoint10, Then press the function keyCALSave and exit.

(2)The factory parameter values. Hold downCALFunction key for two seconds, the display5c 0.0, Then press the function key

CALDisplayLoc c, Press the function keyCAL,Back to normal window,5cThat the compensation value.

LocThat the lock indicates unlocked.

4,Precautions:

(1), Self-tuning, the other parameters can not be adjusted. ??

(2), Self-tuning required20-40Minutes from the end after tuning needed10-20Stabilization process minutes, during which time fluctuated temperatures are normal.

Fault detection

1, Power is not energized, check the fuse is open, or the socket is plugged.

2After boot constant temperature display, not warming, showing off the heating element.

3After boot if left display high temperature, the right displayHIAOrORAAnd it has been blinking, open thermocouple, or temperature controller failure.

Packing List

The product packaging equipment list is as follows:

1Tin stove machine One station

2,user's Guide Hold one

3,Warranty Card Hold one

4, Certificate Hold one

5Tin slag scraperHold one(Except build models)

6,Fuse II only

*********************************************************************************************************************************************
