2024 New High Precision DN6 G1/4 PE Water Flow Sensor
5.0 (1 votes) | 16 orders
Price:
US $15.09
/ piece
Discount Price:
US $
14.33
/ piece
-5%
high precision DN6 G1/4 PE water meter flow sensor counter indicator dispenser flowmeter
Product specification
Order No. | Item item | Number of parameters | Single position | Preparation note |
1 | Start water flow | < 0.2 | L / min (L / min) | |
2 | Starting water pressure | < 0.1 | Mpa (Zhao Pa) | |
3 | Working flow range | 0.28 | L / min (L / min) | |
4 | Pay attention to clean the air impeller on the residual water when the output signal is not higher than 150HZ, idle time should be 30 seconds. | |||
5 | Maximum withstand water pressure | 0.8 | Mpa (Zhao Pa) | |
6 | Operating voltage range | 3.5 ~ 12 | VDC (DC voltage) | DC voltage |
7 | Operating current | 0.51.5 | MA (Hao An) | |
8 | Working environment temperature | 1100 | Degrees Celsius (Celsius) | |
9 | Applicable ambient temperature | 40100 | Degrees Celsius (Celsius) | |
10 | output characteristic | [32*Q]Q for traffic L/min | Hz (Hz) | Error ±3% |
11 | Service life | 106 | H (H) | 5VDC 1mA |
12 | Electrical strength | > 600 | VAC (AC voltage) | Duration of 5S leakage current 3mA |
13 | insulation resistance | m(Million euro | The insulation resistance between the connector and the shell body or the valve body. | |
Packaging Details
- Unit Type: piece
- Package Weight: 0.100
- Package Size: 10x8x20
- Brand Name: LOUCHEN ZM
- Origin: Mainland China
- DIY Supplies: Plumbing
- Model Number: YF-402
- Certification: CE
