1pcs 3.17mm/4mm/5mm/6mm/8mm/10mm/12mm Rigid Shaft Coupling Coupler Motor Connector Sleeve #45 Steel
SALE
NEW
ID: 95740

1pcs 3.17mm/4mm/5mm/6mm/8mm/10mm/12mm Rigid Shaft Coupling Coupler Motor Connector Sleeve #45 Steel

4.8 (272 votes) | 575 orders
Price: US $10.34 - 11.44 / piece
Discount Price:
US $ 9.95 - 10.43 / piece
-4%
Quantity

Notice: Different bore diameters have different outside diameter, please read the table in the description carefully.


The rigid coupling is 90 degree fastening design, and is fastened by four machine screws.


Material: No. 45# steel (GB), ASTM1045, 080M46, not stainless steel


Length:22mm


Outer Diameter: 14mm,16mm, 20mm


Diameter is 14mm, Length is 22mm


3.17mm-3.17mm, 4mm-4mm, 4mm-5mm, 4mm-6mm, 5mm-5mm, 5mm-6mm, 5mm-8mm, 6mm-6mm, 6mm-8mm, 8mm-8mm


Screw Hole Diameter: 4mm


Diameter is 16mm, Length is 22mm


6mm-10mm, 8mm-10mm, 10mm-10mm


Screw Hole Diameter: 4mm


Diameter is 20mm, Length is 22mm


8mm-12mm, 10mm-12mm, 12mm-12mm


Screw Hole Diameter: 5mm


Transfer Bore Diameter: Multiple Specification


Widely used in motor, hardware, mold, mechanical transmission occasions.


For example: the Specification "5mm-8mm" means "one bore diameter of the coupler is 5mm ,the other is 8mm"

Specification

Diameter*Length

Side Hole

Specification

Diameter*Length

Side Hole

3.17mm-3.17mm

14*22mm

M4

6mm-8mm

14*22mm

M4

4mm-4mm

14*22mm

M4

8mm-8mm

14*22mm

M4

4mm-5mm

14*22mm

M4

6mm-10mm

16*22mm

M4

4mm-6mm

14*22mm

M4

8mm-10mm

16*22mm

M4

5mm-5mm

14*22mm

M4

10mm-10mm

16*22mm

M4

5mm-6mm

14*22mm

M4

8mm-12mm

20*22mm

M5

5mm-8mm

14*22mm

M4

10mm-12mm

20*22mm

M5

6mm-6mm

14*22mm

M4

12mm-12mm

20*22mm

M5


Package Included:


Coupler x 1


Screw x 4


Spanner x 1


  • Brand Name: NoEnName_Null
  • Certification: None
  • Origin: CN(Origin)
  • Standard or Nonstandard: Standard
  • Flexible or Rigid: Rigid
  • Material: 45# Steel
