L709CER
SMD RF Power PIN Diode, RoHS Compliant, 180V, 2A, 1W, Ceramic MELF
• Litec RF Diode
• RF Power PIN Diodes
• SMD RF Diodes
• RF Switching Diode
• Ceramic PIN Diodes
• Surface Mount Switching Diodes
• PIN Switch Diodes
• LITEC Power PIN Diodes are designed for RF switch applications such as land mobiles, Ham radios and so on. They are particularly suited for antenna switches of wireless communication relay equipments, RF attenuator, phase shifter and RFID
• Designed for solid-state antenna switches of high-frequency power switch used in commercial two-way radios
• The L709CE PIN diode is designed for solid state antenna switching applications in mobile radios
• The L709CE PIN employs a square outline which makes it suitable for reflow assembly on surface mounting (Exempted by RoHS regulations)
Applications:
[1] High power antenna switch
[2] High Frequency Power Switch
[3] Suitable for wireless communication equipments
Features:
[1] High Power Handling
[2] Low Capacitance at Zero Bias, Extremely Small Reverse Bias
[3] Low Forward Bias Resistance
[4] Very Low Insertion Loss, High Isolation
[5] Surface Mount Ceramic MELF package
[6] RoHS Compliant
[7] Lead-Free Type
• Switching Power: 100W
• Repetitive Peak Reverse Voltage(VRM)(Max): 180V
• Reverse Voltage(VR)(Max): 180V
• Forward Surge Current(IFSM)(Max): 2A(t = 5sec)
• Power Dissipation(P): 1W
• Reverse Current(IR)(Max): 10μA(VR = 50V)
• Diode Capacitance(Ct)(Max): 1.2pF(VR = 40V , f = 1MHz)
• Forward Series Resistance(rfs)(Typ): 0.5Ω(IF = 50mA , f = 100MHz)
• Forward Series Resistance(rfs)(Max): 0.75Ω(IF = 50mA , f = 100MHz)
• Parallel Resistance(RP)(Min): 1kΩ(VR = 0V , f = 100MHz)
• Parallel Resistance(RP)(Typ): 3kΩ(VR = 0V , f = 100MHz)
• Junction Temperature(TJ): 175°C
• Storage Temperature Range(Tstg): -55°C to +175°C
• Brand Name: Litec
• Mounting Type: SMD(Surface-Mounted Device)
• Package: Ceramic MELF
• Packing: 1,500 units / reel
• SMD RF Power PIN Diodes Mass Stock
